The TZY-ASD series intelligent anti shake device is a controller developed to solve the problem of equipment shutdown accidents caused by unstable grid voltage during continuous production. It can detect the voltage status of the equipment in real time. If the grid voltage suddenly shakes and quickly returns to normal within the set time, the controller can restart the equipment to restore operation and avoid production accidents.

1. Environmental conditions: ambient temperature -30~70 ℃, relative humidity ≤ 95% RH

2. Control range of shaking time: 0.5 seconds to 4 seconds

3. Restart time: The frequency converter mode is less than 1 second, and the AC contactor is 0.3 seconds

4. Start contact output form: passive normally open output. 220VAC 5A

5. Reset contact output form: passive normally open output. 220VAC 5A

6. Operation contact output form: passive normally open output. 220VAC 5A

7. Power supply: 160V-260V AC power supply, 50Hz

8. Dimensions: 120 × 96 × 64 millimeters

9. Installation method: 35mm rail installation

10. Installation and wiring instructions: The controller should be installed in a control box that meets the environmental conditions specified in the manual. Suitable vibration reduction and fixing devices can be installed in strong vibration and impact environments.
