2.1 Purpose of the device

The TZY-YZG overvoltage suppression cabinet is suitable for medium voltage power systems ranging from 3 to 35 kV. This product is widely used in power systems with neutral points not grounded, neutral points grounded through arc suppression coils, or neutral points grounded through high resistance. It can limit various types of overvoltage in the above systems and effectively improve the operation and power supply reliability of the above systems.

2.2 Characteristics of the device

It can limit various types of overvoltage to a lower level, greatly reducing insulation accidents caused by overvoltage.

The probability of metal oxide zinc arrester (MOA) explosion in such power grids is greatly reduced.

The system does not require any additional harmonic elimination devices, and its effectiveness is better.

The entire device and PT form a high-voltage switchgear, with a simple structure, small size, easy installation and debugging, and a wide range of applications.

Terms of Use

The TZY-YZG overvoltage suppression cabinet produced by our company is an intelligent device with a high-performance microprocessor as its core component. When used, it must meet the following working conditions without special requirements or permits:

3.1 Power supply voltage: AC/DC 220V ± 10%;

3.2 Environmental temperature: -30 ℃ to+60 ℃; At the same time, the average temperature of the month is ≤+25 ℃;

3.3 Atmospheric conditions: The monthly average relative humidity at the installation site is ≤ 90%, and the daily average relative humidity is ≤ 95%;

3.4 Pollution level: There are no corrosive or explosive media that seriously affect the insulation performance of the device.

For damages caused by unauthorized use outside the scope, our company is not responsible for warranty during the warranty period, but we can provide paid repair services.

4.1 Rated frequency: 50Hz;

4.2 Rated voltage: 3, 6, 10, 35kV;

4.3 Rated 2ms square wave current: 2000A 3200A.
